KM150 – Adjustable connector
The KM150 Adjustable Connector (Ø42.4×2.0 mm) is a stainless steel handrail joint with a option to have an powder-coated RAL finish, allowing 0–90° angle adjustment for stairs and slopes. Strong, elegant, and easy to install — ideal for modern aluminium railing systems.
Estimated production time is 5 weeks.
Price range: 13,99 € through 27,99 €
- Description
- Technical Specifications
- Material and Finish
- Performance and Application
- Maintenance Information
- Packaging and Delivery
The KM150 Connector is a robust adjustable stainless steel joint designed for connecting 42.4×2.0 mm round handrails at variable angles from 0° to 90°. Its pivoting design allows smooth angle adjustment on-site, making it ideal for stairways, ramps, and sloped railing installations.
Engineered for both durability and aesthetics, this connector ensures a precise and clean alignment of handrail sections in any architectural application.
-
Product name: KM150 Connector 42.4×2.0 mm (adjustable 0–90°)
-
Material: Stainless steel(AISI 304 or AISI 316)
-
Surface finish: 320 GRIT, option to have powder-coated finish(available in all RAL colour tones)
-
Diameter: Ø 42.4 mm
-
Wall thickness: 2.0 mm
-
Adjustment range: 0°–90°
-
Net weight: 0.47 kg
Manufactured from high-quality stainless steel, the KM150 Connector combines excellent mechanical strength. Optional powder-coated surface (available in RAL colors).
The finish provides both corrosion protection and design flexibility — perfectly matching aluminium or stainless steel railing systems.
-
Enables angle adjustment from 0° to 90°, suitable for sloped or irregular stair sections
-
Designed for round handrails Ø42.4×2.0 mm
-
Provides secure and precise alignment between handrail elements
-
Ideal for indoor and outdoor applications such as balconies, staircases, and ramps
-
Corrosion protection: C3 (ISO 12944-2) – suitable for outdoor and coastal environments
-
Maintenance: Easy to clean with a soft cloth and mild detergent
Each connector is individually protected to prevent scratches and damage during transport.
